What information do I need to request switchgear?

Send as much technical information as you know. A one-line diagram, shop drawings, nameplate photos, old quote, or equipment photos can be enough to begin — voltage class, bus rating, and configuration are helpful but not required.

Can GridGear source medium-voltage switchgear?

Yes. We source medium-voltage metal-clad and metal-enclosed switchgear, padmount distribution gear, and related lineups across common voltage classes.

Can GridGear help find replacement breakers?

Yes. We help locate replacement MV breakers and compatible components when a full lineup is not required or when breakers are the critical missing piece.

What if I need gear to match an existing lineup?

Note the existing manufacturer and model in your request. Matching existing gear is often possible but depends on availability. Upload photos and drawings of the existing lineup when available.

Can GridGear coordinate inspection, testing, freight, or logistics?

Yes. We coordinate third-party inspection, breaker testing, freight, and rigging through qualified partners to support a higher-confidence transaction.

Switchgear Sourcing

Medium-voltage switchgear, transfer equipment, and electrical lineups when factory lead times or matching existing gear is the problem.

GridGear helps procurement teams locate medium-voltage and large low-voltage switchgear when a new factory order will not meet the schedule, specified gear is obsolete, or a replacement has to match voltage, bus rating, interrupting rating, breaker type, or lineup configuration. We also source generator paralleling gear, automatic transfer switches, and transfer switchgear for backup-power and data-center applications.

Request a Switchgear Quote

Request a Quote Sell Equipment Contact

Equipment families GridGear sources

Primary emphasis is medium-voltage metal-clad and metal-enclosed switchgear, pad-mounted distribution gear, generator paralleling packages, and transfer equipment. These are sourcing capabilities, not a public inventory.

Medium-Voltage Metal-Clad Switchgear

Request Quote

Metal-clad MV lineups for data centers, utilities, industrial plants, substations, and other critical-power applications. Drawout vacuum breakers are the usual match; legacy air-magnetic breakers are also in scope.

Voltage class

5 kV class
15 kV class
27 kV class
38 kV class

System voltage

2.4 kV
4.16 kV
12.47 kV
13.2 kV
13.8 kV
24.94 kV
34.5 kV

Bus / ampere rating

1,200 A
1,600 A
2,000 A
3,000 A
4,000 A+

Interrupting / short-circuit rating

25 kA
31.5 kA
40 kA
50 kA
63 kA

Breaker / device

Drawout vacuum breakers
Legacy air-magnetic breakers

Additional specifications

Construction / enclosure

Metal-clad
Indoor
Outdoor
Arc-resistant
E-house

Common configurations

Main only
Incoming + feeders
Main-tie-main
Main-main
Feeder lineup

Common applications

Data centers
Utilities
Industrial
Substations
Critical power

Medium-Voltage Metal-Enclosed Switchgear

Request Quote

Metal-enclosed MV gear for utility and industrial distribution, campuses, and transformer-primary switching. Typical devices include fused load-interrupter switches, non-fused switches, and vacuum interrupters.

Voltage class

5 kV class
15 kV class
27 kV class
38 kV class

System voltage

4.16 kV
12.47 kV
13.2 kV
13.8 kV
24.94 kV
34.5 kV

Bus / ampere rating

600 A
1,200 A
2,000 A

Interrupting / short-circuit rating

Application-specific
Up to 40–63 kA by design

Breaker / device

Fused load-interrupter switch
Non-fused switch
Vacuum interrupter / breaker

Additional specifications

Construction / enclosure

Metal-enclosed
Indoor
Outdoor

Common configurations

Sectionalizing
Incoming + feeders
Transfer
Transformer-primary switching

Common applications

Utility distribution
Industrial distribution
Campuses
Transformer protection

Pad-Mounted Switchgear

Request Quote

Outdoor dead-front distribution switchgear for utility, data-center campus, solar/BESS, and industrial loop or radial systems. Fused, non-fused, and vacuum / fault-interrupter devices are in scope.

Voltage class / system voltage

15 kV class
25 kV class
35 kV class

Bus / ampere rating

600 A
1,200 A

Interrupting / short-circuit rating

Design-specific

Breaker / device

Fused switch
Non-fused switch
Vacuum / fault interrupter

Additional specifications

Construction / enclosure

Outdoor
Dead-front
Air / gas / solid dielectric

Common configurations

Loop
Radial
Sectionalizing
Multi-way

Common applications

Utility distribution
Data-center campuses
Solar / BESS
Industrial

Generator Paralleling Switchgear

Request Quote

Paralleling gear for multi-generator, utility-paralleling, and backup-power applications in data centers, healthcare, industrial plants, and microgrids. Indoor, outdoor, and e-house packages are all in scope.

Voltage class / system voltage

480 V
600 V
MV systems to 27 kV

Bus / ampere rating

1,600 A
2,000 A
3,000 A
4,000 A
6,000 A+

Interrupting / short-circuit rating

System-specific

Breaker / device

LV power breakers
Insulated-case breakers
MV vacuum breakers

Additional specifications

Construction / enclosure

Indoor
Outdoor
E-house

Common configurations

Isolated generator bus
Utility paralleling
Main-tie-generator
Multi-generator
Load shed / sync

Common applications

Data centers
Healthcare
Industrial
Microgrids
Mission-critical backup

Automatic Transfer Switches and Transfer Switchgear

Standalone ATS equipment and transfer switchgear lineups are grouped here because buyers often need one or the other for the same backup-power or source-transfer problem. The ratings and device types remain distinct.

Automatic Transfer Switch (ATS)

Request Quote

Enclosed automatic transfer switches for critical loads in data centers, healthcare, telecom, and life-safety applications. Contactor, molded-case, and power-frame / breaker ATS devices are in scope.

Voltage class / system voltage

208 V
240 V
480 V
600 V

Bus / ampere rating

40 A to 5,000 A

Interrupting / short-circuit rating

WCR / system-specific

Breaker / device

Contactor
Molded-case
Power-frame / breaker

Additional specifications

Construction / enclosure

Enclosed ATS
Fixed
Drawout
Bypass-isolation

Common configurations

2-pole
3-pole
4-pole
Open transition
Closed transition
Delayed / in-phase

Common applications

Data centers
Healthcare
Telecom
Life safety
Critical loads

Automatic Transfer Switchgear

Request Quote

Transfer switchgear and switchboard lineups for utility-generator and multi-source distribution. Used where the transfer function is built into a lineup rather than a standalone ATS.

Voltage class / system voltage

480 V
600 V
MV transfer systems

Bus / ampere rating

800 A
1,200 A
1,600 A
2,000 A
3,000 A
4,000 A
5,000 A+

Interrupting / short-circuit rating

System-specific

Breaker / device

ATS devices
LV power breakers
MV vacuum breakers

Additional specifications

Construction / enclosure

Switchgear lineup
Switchboard lineup
E-house

Common configurations

Main-main
Main-tie-main
Utility-generator
Generator-generator
Multi-source

Common applications

Data centers
Healthcare
Industrial
Mission-critical distribution

Additional switchgear capability

Low-voltage switchgear, switchboards, and replacement MV circuit breakers are also sourced when they are the practical fit.

Low-Voltage Switchgear

Request Quote

Low-voltage power switchgear for data centers, industrial plants, healthcare, and commercial campuses. Drawout LV power breakers and insulated-case breakers are the usual device types.

Voltage class / system voltage

480Y/277 V
600 V
Up to 600 V class

Bus / ampere rating

1,600 A
2,000 A
3,000 A
4,000 A
5,000 A
6,000 A+
10,000 A by platform

Interrupting / short-circuit rating

42 kA
65 kA
100 kA
150 kA
200 kA

Breaker / device

Drawout LV power breakers
Insulated-case breakers

Additional specifications

Construction / enclosure

Metal-enclosed
Indoor
Outdoor
Arc-resistant

Common configurations

Main only
Main-tie-main
Main-main
Incoming + feeders
Double-ended

Common applications

Data centers
Industrial
Healthcare
Commercial campuses

Switchboards

Request Quote

Front-access switchboards for commercial, industrial, data-center, and service-entrance distribution. Molded-case, insulated-case, and drawout breakers are in scope.

Voltage class / system voltage

120/240 V
208Y/120 V
240 V
480Y/277 V
600Y/347 V

Bus / ampere rating

800 A
1,200 A
1,600 A
2,000 A
3,000 A
4,000 A
6,000 A

Interrupting / short-circuit rating

Up to 200 kAIC

Breaker / device

Molded-case breakers
Insulated-case breakers
Drawout breakers

Additional specifications

Construction / enclosure

Indoor
Outdoor
Front-access
Service entrance

Common configurations

Main + feeders
Single-ended
Double-ended
Close-coupled transformer

Common applications

Commercial
Industrial
Data centers
Service entrance

Replacement MV Circuit Breakers

Request Quote

Direct-replacement, retrofit, and spare medium-voltage breakers for existing cubicles. Used when a full lineup is not required, including planned outages and emergency replacement.

Voltage class / system voltage

5 kV class
15 kV class
27 kV class
38 kV class

Bus / ampere rating

600 A
1,200 A
1,600 A
2,000 A
3,000 A
4,000 A

Interrupting / short-circuit rating

25 kA
31.5 kA
40 kA
50 kA
63 kA

Breaker / device

Drawout vacuum
Fixed vacuum
Legacy air-magnetic

Additional specifications

Construction / enclosure

Existing cubicle compatibility
Racking / interlocks

Common configurations

Direct replacement
Retrofit
Spare breaker
Outage recovery

Common applications

Legacy switchgear
Modernization
Planned outages
Emergency replacement

When to Call GridGear

Reach out when the usual OEM or distributor path is not producing a workable option in time.

Factory lead time will not meet the schedule
Specified gear is obsolete or no longer available
A replacement or expansion has to match an existing lineup
Voltage, bus rating, interrupting rating, or breaker type has to match
Temporary gear is needed until permanent equipment arrives
The project needs paralleling, ATS, or backup-power distribution

Frequently Asked Questions

What information do I need to request switchgear?: Send as much technical information as you know. A one-line diagram, shop drawings, nameplate photos, old quote, or equipment photos can be enough to begin — voltage class, bus rating, and configuration are helpful but not required.
Can GridGear source medium-voltage switchgear?: Yes. We source medium-voltage metal-clad and metal-enclosed switchgear, padmount distribution gear, and related lineups across common voltage classes.
Can GridGear help find replacement breakers?: Yes. We help locate replacement MV breakers and compatible components when a full lineup is not required or when breakers are the critical missing piece.
What if I need gear to match an existing lineup?: Note the existing manufacturer and model in your request. Matching existing gear is often possible but depends on availability. Upload photos and drawings of the existing lineup when available.
Can GridGear coordinate inspection, testing, freight, or logistics?: Yes. We coordinate third-party inspection, breaker testing, freight, and rigging through qualified partners to support a higher-confidence transaction.
